RB2011UAS-2HnD-IN KAM Fab Desktop Kit

SKU:
K-RB2011UAS-2HnD-IN-D
Availability:
In stock Items usually ship within 24 hours, see our stock policy.
$145.00
(No reviews yet)
Weight:
3.00 LBS
Current Stock:
Adding to cart… The item has been added

Product Description

RouterBOARD 2011UAS-2HnD has most features and interfaces from all our Wireless routers. It’s powered by the new Atheros 600MHz 74K MIPS network processor, has 128MB RAM, five Gigabit LAN ports, five Fast Ethernet LAN ports and SFP cage (SFP module not included!). Also, it features powerful (up to 1W!) dual chain 2.4Ghz 802.11bgn wireless, RJ45 serial port, microUSB port and RouterOS L5 license, as well as desktop case with power supply, two 4dBi Omni antennas and LCD panel



Product specifications

Details
Product code RB2011UAS-2HnD-IN
Antenna gain 4dbi
TX power 30dBm
Current Monitor No
CPU Atheros AR9344
Max Power consumption 11W
SFP ports 1
CPU speed 600MHz
RAM 128MB
LAN ports 5
Gigabit 5
MiniPCI 0
Integrated Wireless yes
Wireless standards 802.11b/g/n
USB microUSB
Power Jack 8-28V DC
802.3af support No
PoE 8-28V DC on Ether1
Voltage Monitor Yes
CPU temperature monitor No
PCB temperature monitor Yes
Dimensions 214mm x 86mm for PCB
Operating System RouterOS
Temperature range -35C to +65C
RouterOS License L5

Throughput results

RB2011 Series @600Mhz (Dual chain throughput test)64 byte frames512 byte frames1518 byte frames
IP FirewallConntrackModeMbpsFpsMbpsFpsMbpsFps
off off Bridging 38.04 74300 200.7 49000 224.66 18500
on off Routing 32.36 63200 190.87 46600 224.66 18500
on off Bridging 26.27 51300 165.89 40500 224.66 18500
on on Routing 26.27 51300 166.71 40700 224.66 18500
on on Bridging 21.56 42100 135.17 33000 199.16 16400
RB2011 Series @600Mhz (Ethernet only test)64 byte frames512 byte frames1518 byte frames
IP FirewallConntrackModeMbpsFpsMbpsFpsMbpsFps
off off Bridging 77.31 151000 595.15 145300 1244.76 102500
on off Routing 65.95 128800 518.14 126500 1167.04 96100
on off Bridging 47.82 93400 368.64 90000 992.16 81700
on on Routing 41.22 80500 333 81300 952.09 78400
on on Bridging 34.1 66600 264.6 64600 765.07 63000
    Notes:
  1. All throughput tests done with Xena Networks specialized test system and RouterOS v5, according RFC2544, with Ethernet frame sizes 64, 512, 1518 bytes.Each board is tested with specified number of Ethernet interfaces, to ensure optimal load on hardware.
  2. Values in Italics indicate that the maximum possible throughput was reached, limited only by ethernet ports themselves.
