airMAX RocketDish, 5 GHz, 34 dBi Antenna

SKU:
RD-5G34
|
UPC:
810354021299
Availability:
In stock items usually ship within 24-48 hours, unless marked Pre-Order! See our stock policy for more information
$329.00
(No reviews yet)
Weight:
200.00 LBS
Current Stock:
Adding to cart… The item has been added

airMAX® 2x2 PtP Bridge Dish Antenna Pair the RocketDish™ with a Rocket™M BaseStation for Point‑to‑Point (PtP) bridging and network backhauls.

Dimensions:
1050 x 1050 x 421 mm (41.34 x 41.34 x 16.57")
Weight:
13.5 kg (29.76 lb)
Frequency Range:
4.9 - 5.8 GHz
Gain:
4.9 GHz: 30 dBi // 5 - 5.8 GHz: 34 dBi
HPOL Beamwidth:
3° (3 dB)
VPOL Beamwidth:
3° (3 dB)
F/B Ratio:
42 dB
Max. VSWR:
1.4:1
Wind Loading:
1,779 N @ 200 km/h (400 lbf @ 125 mph)
Wind Survivability:
200 km/h (125 mph)
Polarization:
Dual-Linear
Cross-pol Isolation:
35 dB Min.
ETSI Specification:
EN 302 326 DN2
Mounting:
Universal Pole Mount, Rocket Bracket, and Weatherproof RF Connectors Included
